Power Source : 1.5 V DC (Battery)
Receiving Frequencies : 470 MHz band (5 ch) (470.075, 470.150, 470.375, 470.625, 470.725 MHz)
Receiving System : Double super-heterodyne
Receiving Sensitivity : 25 dB or more, Signal to Noise ratio (7 dBμVEMF input, ±1.7 kHz deviation)
Frequency Response
- 200 Hz – 5 kHz (Portable transmitter → Potable receiver)
- 150 Hz – 6 kHz (Desk-top transmitter → Potable receiver)
De-emphasis : 50 μs
Output Level : 4 mW (16 Ω load, 10 % distortion)
Battery Life : 18 hours (alkaline)
Battery : LR6 (1.5 V) × 1
Operation Temperature : -10 ℃ to +40 ℃
Finish : Resin, dark silver
Dimensions : 62 (W) × 163.6 (H) × 32.5 (D) mm
Weight : 112 g (battery included)
Accessory : Neck strap x 1
