Power Source : 100 – 240 V AC, 50/60Hz
Rated Output : 240 W
Power Consumption : 62 W (AC operation at 1/8 maximum output without clip)
Frequency Response : 50 – 20,000 Hz
Input :
- MIC 1: 1 mV (-60 dB*), 600 Ω, balanced, phone jack, selectable to RJ45
- MIC 2-3: 1 mV (-60 dB*), 600 Ω, balanced, phone jack
- MIC 4: 1 mV (-60 dB*) 600 Ω, balanced, phone jack, selectable to AUX 1
- AUX 1: 100 mV (-20 dB*), 10 kΩ, unbalanced, RCA pin jack, selectable to MIC 4
- AUX 2: 100 mV (-20 dB*), 10 kΩ, unbalanced, RCA pin jack
- MP3: LED Display, Support USB, SD/MMC card (up to 32GB), Bluetooth, Radio FM, Record
Output :
- Speaker out: Speaker Output in screw type terminal
- Direct line (selectable): 42 Ω (100 V) or 4 Ω
- Rec out: 0 dB*, 600 Ω, unbalanced, RCA pin jack
- 5-zone selector (all zones simultaneously selectable)
Phantom Power : DC +21 V (MIC 1)
S/N Ratio : Over 60 dB
Total Harmonic Distortion : Under 1% at 1 kHz, 1/3 rated power
Tone Control :
- Bass: ±10 dB at 100 Hz
- Treble: ±10 dB at 10 kHz
Muting : MIC 1: Mutes other input signals by 0-30 dB attenuation
Indicator : Power, Signal , Peak, Protect
Ventilation : Fan Cooling
Finish :
- Panel: ABS resin, black
- Case: Steel plate, black
Dimensions : 420 (W) × 100.9 (H) × 357 (D) mm
Weight : 4.9 kg
Accessory : Removable terminal plug (2 pins) x 5, Antenna FM radio (1m) x 1
