Enclosure : 2-way bass-reflex type
Rated Input : 30 W
Rated Impedance :
- 8 Ω
- 100 V line: 330 Ω (30 W), 500 Ω (20 W), 670 Ω (15 W), 1 kΩ (10 W), 2 kΩ (5 W)
- 70 V line: 170 Ω (30 W), 250 Ω (20 W), 330 Ω (15 W), 500 Ω (10 W), 1 kΩ (5 W)
Sound Pressure Level : 90 dB (1 W, 1 m)
Frequency Response : 80 Hz – 20 kHz
Speaker Component : 12 cm cone-type + dome-type
Speaker Cord : 2-core cabtyre cord with diameter of 6 mm
Operating Temperature : -10 ℃ to +50 ℃
Water Protection : IPX4 (can be installed vertically or horizontally.*)
Finish :
- Enclosure: ABS resin, black (RAL9011 GRAPHITE BLACK), paint
- Net: Surface treated steel plate, black (RAL9011 GRAPHITE BLACK), powder coating
- Bracket: Surface treated steel plate, black equivalent to RAL9011 GRAPHITE BLACK,
- powder coating
Dimension : 196 (W) × 290 (H) × 150 (D) mm (unit only)
Weight : 2.5 kg (unit only)
Accessory : Bracket…1, Bracket mounting screw…2, Bracket mounting washer…2
