Power Source : 6V DC (4x “AA” batteries) or DC adapter: 9-24V
Current Consumption : 13 mA during chime and 6 mA microphone operation
Microphone Element : Condenser
Polar Pattern : Cardioid
Chime Tones : 4-Tone Chime (UP/DOWN)
Rated Impedance : 600 Ω, balanced
Output :
- Microphone: -41 dB ±3dB (1 kHz 0 dB=1 V/Pa)
- Chime Tones: -31 dB ±3dB (maximum position)
Frequency Response : 50 Hz – 18,000 Hz
Output Connector :
- XLR-3-32 equivalent
- RJ45: Audio Output, Power Supply and contact output
Operating Temperature : 0 °C to +40 °C
Finish :
- Stand Mic: ABS resin, black, paint
- Mic Shaft: Copper alloy, black, paint
Dimensions : 110 (W) × 145 (L) x 532 (H) mm
Weight : 558 g (exclude batteries)
Accessory : Windscreen x 1, XLR Cable Stereo Phone Plug (7.5m) x 1
