Enclosure : Sealed type
Rated Input : 60 W (High Impedance)
Power Handling Capacity
- Continuous pink noise: 100 W (Low Impedance)
- Continuous program: 300 W (Low Impedance)
Rated Impedance
- 8 Ω
- 100 V line: 170 Ω (60 W), 330 Ω (30 W), 670 Ω (15 W)
- 70 V line: 83 Ω (60 W), 170 Ω (30 W), 330 Ω (15 W), 670 Ω (7.5 W)
Sensitivity : 97 dB (1 W, 1 m)
Frequency Response : 70 – 20,000 Hz
Crossover Frequency : 3 kHz
Directivity Angle : Horizontal: 90゜, Vertical: 40゜
Speaker Component : Low frequency: 30 cm (12″) cone-type, High frequency: Balanced dome tweeter × 6
Input Terminal : NEUTRIK NL4MP Speakon and M4 screw terminal, distance between barriers: 9 mm (0.35″)
Operating Temperature : -10℃ to +50℃ (14゜F to 122゜F)
Finish
- Enclosure: Polypropylene, black
- Punched net: Surface-treated steel plate, black
Dimensions : 361 (W) × 448 (H) × 320 (D) mm (14.21″ × 17.64″ × 12.6″)
Weight : 10 kg (22.05 lb)
Accessory
- Handle …1
- Handle fitting bracket …2
- Handle mounting screw …2
- Rubber foot …2
- Rubber foot mounting screw …2
Option
- Mounting bracket: HY-1200VB (for vertical speaker mounting)
- HY-1200HB (for horizontal speaker mounting)
- Ceiling mount bracket: HY-C0801
- Wall mount bracket: HY-W0801
- Speaker stand: ST-33B
