(*) 0 dB = 1V
(**) A USB 2.0-compatible FAT32-formatted flash memory device of up to 32GB in capacity can be used.
There may be cases in which a USB flash drive cannot be used with the TS-890RC, depending on the drive’s attributes or recording conditions.
Power Source : 100 – 240 V AC, 50/60 Hz (use of the supplied AC adapter)
Power Consumption : 72 W
Current Consumption : Max. 3 A DC (when 24 V DC is supplied from the accessory AC adapter)
Carrier Frequency
- Reception:
– Audio Channel 1: 7.35 MHz
– Audio Channel 2: 8.10 MHz
– Audio Channel 3: 8.55 MHz
– Audio Channel 4: 9.15 MHz
– Control Channel: 6.45 MHz - Transmission
– Audio Channel: 1.95 MHz
– Translation Language Channel: 2.25 MHz
Input
- MIC 1 (Base Language): -60 dB*, 600 Ω, unbalanced, Ø 6.3mm phone jack (2P)
- MIC 2 (Translation Language): -60 dB*, 600 Ω, unbalanced, Ø 6.3mm phone jack (2P)
- AUX 1 (Base Language): -20 dB*, 10 kΩ, unbalanced, Ø 6.3mm phone jack (2P)
- AUX 2 (Translation Language): -20 dB*, 10 kΩ, unbalanced, Ø 6.3mm phone jack (2P)
- AUX 3 (Base and Translation Language): -20 dB*, 10 kΩ, unbalanced, Ø 6.3mm phone jack (2P)
Output
- LINE: -10 dB*, 10 kΩ, unbalanced, Ø 6.3mm phone jack (2P)
- REC: -10 dB*, 10 kΩ, unbalanced, RCA pin jack
- HEADPHONE: Ø 3.5mm mini jack (3P: monaural)
Equalizer Input/Output
- Input: -20 dB*, 10 kΩ, unbalanced, RCA pin jack
- Output: -20 dB*, 10 kΩ, unbalanced, RCA pin jack
Number of Connectable Chairman/Delegate Units : 192 units
Number of Connectable Infrared Transmitter/Receiver Units
- Up to 4 units (with the use of distributor
- up to 16 units connectable when they are all TS-905
- up to 12 units when they are all TS-907, or TS-905 and TS-907 are used in combination)
Infrared Transmitter/Receiver I/O Terminal : BNC jacks
External Control Connection Terminal : D-sub connector (9 P, male) / USB-B selectable
LED Indicator : Voting result indicators 1-3 (7-segment LED, 3 digits), Short-circuit indicator, Audio signal receiving indicators 1 – 4 CH, Data signal receiving indicator, External control priority indicator, External control communication indicator, Battery indicator (flashes when a Chairman/Delegate unit’s battery nears complete discharge), Recording status indicator, Format in-progress indicator, Access indicator, Internal memory status indicator, USB memory status indicator, Remaining internal memory capacity warning indicator, Remaining USB memory capacity warning indicator
Record Switch : Recording start button, Recording stop button, Format button
Recording Ports : USB-A (for USB memory devices) and USB mini-B (for PCs)
Recording Function
- Recordings can be made to a USB memory device (**) or the internal memory.
- Recording format :
– MP3 (MPEG-1 Audio Layer-3), monaural
– Sampling frequency: 32 kHz, Bit rate: 128 kbps
Function Switch
- No. of open microphones setting switch: 1/2/3/4
- Mic-off setting switch: TIME OUT ON/OFF
- Speech priority selector switch: FIRST (First-in-first-out priority), LATEST (Last-in-first-out priority), FIRST: FIXED NEXT: LATEST (Priority ixed for the first unit, and last-in-first-out for all other subsequent units)
- FBS switch: AUTO/OFF/EXT
Operating Temperature : 0 ℃ to +40 ℃ (32 ゜F to 104 ゜F)
Operating Humidity : 90 %RH or less (no condensation)
Finish : Panel: Surface-treated steel plate, black, 30% gloss, paint
Weight : 2.8 kg (5.95 lb)
Accessory : AC adapter (Cord length: 1.8 m (5.91 ft) DC cord, and 2 m (6.56 ft) detachable AC cord)…1
Option : Rack mounting bracket: MB-TS920
Operating Software Features
- Control up to 4 IP camera (Onvif)
- Control speech time
- Selection of Chairman or Delegate unit for speech request and approval
- Ability to map actual conference layout in software display
