Applicable Horns : TH-650, TH-660
Rated Input : 60 W
Line Voltage : 100 V line or 70 V line
Rated Impedance
- 100 V line: 170 Ω (60 W), 330 Ω (30 W), 670 Ω (15 W)
- 70 V line: 83 Ω (60 W), 170 Ω (30 W), 330 Ω (15 W), 670 Ω (7.5 W)
Sensitivity : 110 dB (1 W, 1 m) (When operated with JIS C 5504 standard horn.)
Frequency Response : 150 Hz – 8 kHz (When operated with JIS C 5504 standard horn.)
Dust/Water Protection : IP65 (When a driver is operated with a horn.)
Horn Coupling : 1 – 3/8 18 threads (inch screw)
Polarity : Hot: Black, Com: White
Operating Temperature : -20 ℃ to +55 ℃ (-4 ゜F to +131 ゜F) (no condensation)
Finish
- Flange: Aluminum, gray, powder coating
- Rear cover: ABS resin, gray
- Screws: Stainless steel
- Speaker cable: Polyvinyl chloride insulated cabtyre cable (6 mm (0.24″) in diameter, 600 mm (23.62″) in length)
Dimensions : φ139 × 151 (D) mm (φ5.47″ × 5.94″)
Weight : 2.7 kg (5.95 lb)
Option : Driver unit cover: UC-200A
