Frequency Range : C4/C7 ver.: 794 – 832 MHz, G1 ver.: 606 – 636 MHz
Modulation type : FSK
Channel Selectable : 160 channels (The number of channels may differ from country to country.)
RF Carrier Power : Less than 50 mW
Maximum Input Level : -18 dB (*1) (Sensitivity: L)/-28 dB (*1) (Sensitivity: H)
Audio Frequency Response : 100 Hz – 12 kHz
Antenna : Lamda/4 whip antenna
ID Selectable : 10 patterns
Battery : WB-2000 rechargeable battery (option) or AA Alkaline dry cell battery
Battery Life : Approx. 8 hours
Operating Temperature : -10 ℃ to +50 ℃ (14 ゜F to 122 ゜F) (except battery)
Operating Humidity : 30 % to 85 %RH (no condensation)
Finish : Body: ABS resin, black, paint
Dimensions
- C4/C7 ver.: 62 (W) x 171 (H) x 19 (D) mm (2.44 in x 6.73 in x 0.75 in)
- G1 ver/: 62 (W) x 185 (H) x 19 (D) mm (2.44 in x 7.28 in x 0.75 in)
Weight : 90 g (0.2 lb) (with battery)
Accessory : torage case …1, Screw driver (for setting) …1
Option
- Battery charger: BC-2000 (*2)
- Ni-MH Battery: WB-2000-2 (*2) (containing 2 pieces)
- Unidirectional lavalier microphone: YP-M5300,
- Omnidirectional lavalier microphone: YP-M5310,
- Headset microphone: WH-4000A, WH-4000H
