Power Source : AC mains (supplied AC adapter must be used)
Power Consumption : 200 mA (12 V DC)
Receiving Frequency : 748 – 758 MHz, UHF
Channel Selectable : 64 selectable frequencies
Receiving System : Double super-heterodyne
Diversity System : Space diversity
Mixing Output
- MIC/LINE (selectable) : -60 dB (*1) (MIC)/-20 dB (*1) (LINE), 600 Ω
- phone jack (unbalanced), 600 Ω XLR-3-32 type connector (balanced)
Mixing Input : -20 dB (*1), 10 kΩ, unbalanced, phone jack
Antenna Input : 75 Ω, BNC (phantom powering for antenna), 9 V DC, 30 mA (max)
Receiving Sensitivity : 90 dB or more, Signal to Noise ratio (20 dBμV input, 40 kHz deviation)
Squelch Sensitivity : 16 – 40 dBμV variable
Squelch System : Using together of noise SQ, carrier SQ and tone SQ
Tone Frequency : 32.768 kHz
Indicator : Audio (6 steps), RF (6 steps), ANT A/B, Audio (peak), Battery alarm
Channel Check : Usable frequencies scanning
Signal to Noise Ratio : 110 dB or more (A-weight, unbalanced output)
Harmonic Distortion : 1 % or less (typical)
Frequency Response : 100 Hz – 15 kHz, ±3 dB
Operating Temperature : -10 ℃ to +50 ℃ (14 ゜F to 122 ゜F)
Operating Humidity : 30 % to 85 %RH (no condensation)
Finish : Resin, black
Dimensions : 210 (W) × 44 (H) × 205.1 (D) mm (8.27″ × 1.73″ × 8.07″)
Weight : 700 g (1.54 lb)
Accessory : AC adapter…1
Option :
- Mounting bracket kit: MB-WT3 (for rack mounting one WT-5805C unit)
- MB-WT4 (for rack mounting two WT-5805C units)
