Rated Input : 6 W (100 V line), 3 W (70 V line)
Rated Impedance :
- 100 V line: 1.7 kΩ (6 W), 3.3 kΩ (3 W), 6.7 kΩ (1.5 W), 13 kΩ (0.8 W)
- 70 V line: 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), 6.7 kΩ (0.8 W), 13 kΩ (0.4 W)
Sensitivity : 94 dB (1 W, 1 m) (500 Hz – 5 kHz, pink noise)
Frequency Response : 150 Hz – 20 kHz (peak -20 dB)
Speaker Component : 16 cm (6″) double cone-type
Applicable Cable :
- 600 V vinyl-insulated cable (IV wire or HIV wire)
- Solid wire: φ0.8 – φ1.6 mm (equivalent to AWG 20 – 14)
- 7-core twisted wire: 0.75 – 1.25 m㎡ (equivalent to AWG 18 – 16)
Connection : Push-in connector (bridging terminal)
Attenuation : OFF, 1 (-12 dB), 2 (-6 dB), 3 (0 dB)
Finish :
- Baffle: HIPS, black (RAL 9011 or equivalent color)
- Cabinet: Particle board with pvc sheet, black (RAL 9011 or equivalent color)
- Grille: Surface-treated steel plate net, black (RAL 9011 or equivalent color)
Dimensions : 250 (W) × 190 (H) × 110 (D) mm (9.84″ × 7.48″ × 4.33″)
Weight : 1.7 kg (3.75 lb)
Accessory : Speaker mounting screw (4 × 35 (0.16″ × 1.38″)) …2
