Product
- Composition Wireless Transmitter x 1
- Receiver x 1
- Lavalier Microphone x 1
Frequency Range : 748 – 758 MHz, UHF
Channel Selectable : 4 channels
Tunable Frequencies : 25 kHz Steps
Pilot Tone : 32.768 kHz
Total Harmonic Distortion : <1% @ 1kHz
Function : IR sync, Channel scan, Battery Indicator
Accessory
- AC adapter x 1
- Screw Driver x 1
- Lavalier Microphone x 1
Microphone Element : Back electret condenser; Omni-directional
RF Carrier Power : 10 mW
Audio Frequency Response : 50 – 15,000 Hz
Audio Input Level : -6dBV (Maximum), mic gain 0dB
Modulation System : PLL synthesizer
Battery : 1 AA size alkaline battery, 1.5V
Battery Life : Approx. 10 hours
Indicator Battery : Status LED, 7 Segments LED
Finish : Resin, coating
Dimensions : 62 (W) x 100 (H) x 25 (D) mm (with clip)
Weight : Approx. 85 g (with battery)
Diversity Reception : AC mains (supplied AC-DC adapter must be used)
Sensitivity : 10uV at 45dBA S/N
Squelch (SQ) : Tone SQ, Carrier SQ and Noise SQ
Audio Frequency Response : 50 – 15,000Hz
Audio Output Level (Maximum)
- Balanced (XLR socket): -20dBu
- Unbalanced (1/4″ jack socket): 10dBu
Power Supply : 11-18 VDC 300mA
Dimensions : 215 (W) × 39 (H) × 102 (D) mm (excluding antenna and BNC)
Weight : 480 g
