Performance
| Passenger capacity | 4 seats |
| Max Speed |
≤30 km/h |
| Range (loaded) |
70km |
| Climbing Ability (loaded) |
≤20% |
| Braking Distance |
≤4.5m |
| Min.Turning Radius |
≤5m |
| Min.Clearance | 110mm |
| Recharge time |
8h |
Dimensions
| L x W x H |
3180 x 1260 x 1940 mm |
| F/R Tread |
Front 920mm / Rear 1010mm |
| Axle Distance |
2400mm |
| Curb Weight |
≤680kg (with Battery) |
| Max. loading |
340kg |
Standard Configurations
| Motor | 48V / 5KW / AC motor |
| Controller |
48V 350A controller |
| Battery |
6pcs*8v 150ah Lead-acid batteries |
| Body |
High-strength composite body (PT+PBT alloy injection-molded front cowl) with superb impact resistance. |
| Roof |
High strength ABS injection molding. (Black) |
| Chassis | High-strength steel frame-type longitudinal beam chassis with electrophoresis + plastic spraying anti-rust treatment. |
| Seats | Polyurethane foam + Microfiber leather with seat belt |
| Dashboard | injection molded dashboard with electric lock switch, forward/reverse switch, alarm light switch, light signal switch, 10-inch LCD with Bluetooth function, CarPlay function, speakers, and rear camera. |
| Lighting and Signaling | Front combination headlights (with high/low beams, running lights, override lights), turn signals, rear combination lights, electric horn, reverse buzzer. |
| Steering system | Dual-push rack and pinion steering system. |
| Brake system | Four-wheel hydraulic brake, four-wheel disc brake + electronic brake parking |
| Front Suspension | Independent front suspension with double swing arm + coil spring + cylinder hydraulic shock absorption. |
| Rear suspension | Trailing arm independent suspension with direct motor connection to the integral rear axle. |
| Front windshield and wipers | DOT certified Folding acrylic glass windshield |
| Floor | Rubber floor with diamond pattern. |
| Wheel Rim+Tire | Road 205/50-10 (6 Ply Rated)/tires; P820, aluminum rims |
| Steering wheel | Injection molded steering wheel with scoreboard (R40) |
| Front Bumper | Injection Molded Bumper |
| Other Accessories | Both side mirrors, roof rails, without center mirror. |
| Color Option | Ivory white(Recommend), Toyota white, Maple leaf yellow, Cherry red, Apple red, Crystal gray, black, etc. |
