Performance
| Passenger capacity | 2 seats |
| Max Speed |
32 km/h |
| Range (loaded) |
60-80km |
| Climbing Ability (loaded) |
15% |
| Braking Distance |
≤4m |
| Min.Turning Radius |
3m |
| Min.Clearance | 110mm |
| Recharge time |
8~10h |
Dimensions
| L x W x H |
2370 x 1200 x 1870 mm |
| F/R Tread |
Front 850mm / Rear 970mm |
| Axle Distance |
1640mm |
| Curb Weight |
≤580kg |
| Max. loading |
170kg |
Standard Configurations
| Motor | 48V / 5KW / AC motor |
| Controller |
48V 350A FJ controller |
| Battery |
6pcs*8v 150ah Torch lead-acid betteries |
| Body |
Injection plastic |
| Roof |
Blister plastic |
| Windshield |
Acrylic Flat windshield |
| Seats | Sponge + artificial leather |
| Rear view mirror |
2pcs |
| Bumper | Plastic Front Bumper |
| Floor | Non-slip patterned rubber floor |
| Tire | 205/50-10 on -road tire, with steel rim |
| Chassis | high-strength sheet metal frame; painting process: pickling + |
| Steering | rack and pinion steering |
| Front Suspension |
leaf springs+ hydraulic cartridge damping system |
| Rear Suspension |
mechanical drum brakes+leaf springs |
| Sound system |
Speaker |
| Brake system |
Rear machanical drum brakes, mechanical parking |
| Charger | Automatic high efficiency pulse, Output:48V/20A, Input:AC110/220V |
| Dashboard | Voltameter, Headlight switch, turn signal switch, horn button |
| Optional Accessories | Sand bottles, ball washer, caddy stand. |
| Color Option | Ivory white(Recommend), Toyota white, Maple leaf yellow, Cherry red, Apple red, Crystal gray, Metallic black, etc. |
